Do you have any questions about VET / VEM
Consult our specialists in Vibration
- DURABLE
- FULL RANGE
- ADJUSTABLE FORCE
- IP65 PROTECTION
Customize VET / VEM
VET 100
VET 150
VET 300
VET 600
VET 800
VET 1600
VEM 100
VEM 150
VEM 300
-
CENTRIFUGAL FORCE
- 1 KN
- 16 KN
- 2 KN
- 3 KN
- 5 KN
- 8 KN
-
VOLTAGE
- 1~230V 50HZ
- 3~230/380V 50HZ
Optional accessories
Screw kit 8 mm.
Screw kit 8 mm
Screw kit 12 mm.
Screw kit 12 mm
Flat quick coupling.
Flat quick coupling
External Vibrator VET/VEM
The VET/VEM range of external vibrators offers a wide variety of single-phase and three-phase vibrators at 3,000 rpm.
- Bearings lubricated with high-durability grease.
- Electric motors made with low-loss laminations.
Technical characteristics
| VET 100 | VET 150 | VET 300 | VET 600 | VET 800 | VET 1600 | VEM 100 | VEM 150 | VEM 300 | |
|---|---|---|---|---|---|---|---|---|---|
| (A) DISTANCE | 62-74 mm | 62-74 mm | 90 mm | 105 mm | 120 mm | 140 mm | 62-74 mm | 62-74 mm | 90 mm |
| (B) DISTANCE | 106 mm | 106 mm | 125 mm | 140 mm | 170 mm | 190 mm | 106 mm | 106 mm | 125 mm |
| (C) LENGTH | 225 mm | 233 mm | 257 mm | 338 mm | 325 mm | 416,5 mm | 225 mm | 233 mm | 257 mm |
| (D) WIDE | 130 mm | 130 mm | 155 mm | 170 mm | 208 mm | 230 mm | 130 mm | 150 mm | 155 mm |
| (G) DIAMETER | 9 mm | 9 mm | 13 mm | 13 mm | 17 mm | 17 mm | 9 mm | 9 mm | 13 mm |
| CENTRIFUGAL FORCE | 1 KN | 2 KN | 3 KN | 5 KN | 8 KN | 16 KN | 1 KN | 2 KN | 3 KN |
| PRODUCT | VET 100 | VET 150 | VET 300 | VET 600 | VET 800 | VET 1600 | VEM 100 | VEM 150 | VEM 300 |
| REVOLUTIONS (r.p.m) | 3.000 | 3.000 | 3.000 | 3.000 | 3.000 | 3.000 | 3.000 | 3.000 | 3.000 |
| VOLTAGE | 3~230/380V 50HZ | 3~230/380V 50HZ | 3~230/380V 50HZ | 3~230/380V 50HZ | 3~230/380V 50HZ | 3~230/380V 50HZ | 1~230V 50HZ | 1~230V 50HZ | 1~230V 50HZ |
| WEIGHT | 4,7 kg | 6,3 kg | 9,9 kg | 16,7 kg | 21,8 kg | 53,5 kg | 5,1 kg | 6,8 kg | 10 kg |
